Name: Cosmetic Production Line
Category: Production Line
Model: KZR
Feature: This model is for making top grade cream, ointment, cosmetic, shampoo, honey. The contacting parts made of stainless-steel
Overview
This equipment mainly consists of homogenizing main pot(kettle's cover lifting together with the stirrer-
and overturn body), water-phase pot, oil-phase pot, agitators, vacuum system, electric heating/steam
heating system with temperature control, electrical control etc.
It is special equipment for making top grade cream, pharmaceutical ointment, unguent, shampoo, lotion etc.
Design Highlights
• The pot cover and the stirring system takes the form of automatic lift up & fall down.
• The material in water pot and oil pot is sucked into emulsifying pot is designed to be tilted over in case to dump products.
• Materials can be heated by electrical heater with help of heat-conductive medium.
• The heat temperature can be set and automatically controlled. Material cooling is available.
• It is easy to operate, and there is temperature insulation layer between inner and outer.
• The contacting parts are made of stainless steel (steel SUS316L is used for pharmaceutical purpose,and surface
mirror polished).
• With customized type vacuum stirrer equipment which can be in accordance with GMP standard.
• It is best for the production of ointment, cream, cosmetic, detergent, etc.
Technical Parameter
Model
KRH-D
5L
10L
30L
50L
100L
150L
200L
300L
500L
650L
Emulsifier
Total vol.(L)
6
10
30
50
100
150
200
200
300
500
Capacity(L)
5
8
25
40
80
120
120
160
240
400
Scraper power(kw)
0.18
0.18
0.75
0.75
1.1
1.1
1.5
1.5
1.5
2.2
Scraper speed
10-120rpm
Emulsifier power(kw)
0.55
0.55
1.5
1.5
2.2
3
4
7.5
11
15
Speed
0-2800rpm
Water pot
Volume(L)
5
5
20
35
60
90
120
180
300
300
Capacity(L)
4
4
16
28
50
75
100
150
250
250
Power(kw)
0.018
0.018
0.18
0.18
0.55
0.55
0.75
0.75
1.1
1.1
Speed
60-1000rpm
Oil pot
Volume(L)
5
5
15
25
40
60
80
120
200
200
Capacity(L)
4
4
12
20
35
50
65
100
165
165
Stirrer power(kw)
0.018
0.018
0.37
0.37
0.55
0.55
0.75
0.75
1.1
1.1
Speed
60-1000rpm
Vacuum
Power(kw)
0.12
0.12
0.37
0.37
0.37
0.55
2.2
1.1
1.5
1.5
Vacuum
-0.09Mpa
Lifting
Power(kw)
0.55
0.55
0.75
0.75
0.75
0.75
1.1
1.1
2.2
2.2
Lift ways
Manual
Electric
Hydraulic
Product Application
This equipment is mainly used for laboratory trials or small scale production of cosmetic, honey, ointment, shampoo,
lotion, cream, pharmaceutical-ointment, --- etc.
